Description
Micro size full metal brushed waterproof digital servo, full case in CNC precise engraving, as the diff locking or gear change servo. Fit for TRAXXAS series cars TRX-4/3pcs , TRX-6/3pcs,for AXIAL series SCX10 AXI03003/2pcs, SCX10 III AXI03006/2pcs,Capra 1.9 UTB AXI03004/2pcs
Operating voltage:4.8-6.0V
Operating speed:
5.0V-0.12sec/60°
6.0V-0.11sec/60°
Stall torque:
5.0V-2.5kgf.cm(35oz-in)
6.0V-3.2kgf.cm(44oz-in)
Gear Material:Stainless steel
Horn gear spline:25T Φ4.9
Size:23X13X26mm(0.91×0.51×1.02in)
Case material:Full metal
Weight:20g
Bearing:2BB
Motor type:Brushed
Operating Temperature:-15℃~+70℃
Operating travel :≈180±10°
Neutral position :1520μsec
Frequency:1520uS
Refresh rate:333Hz
Pules width range :500-2500μsec
Dead band width:2μsec
Connector wire length:180mm
Waterproof level:Dust & Water Splash Resistacne
Programmable:No
