Description
Bilstein M 9100 (Bump Stop) is designed to provide a significant increase in compression control over the last few inches of suspension travel on custom off-road applications. M 9100 (Bump Stop) is available in 3 different stroke lengths ranging from 2-4 inch travel that can accommodate a wide range of custom mount configurations. M 9100 (Bump Stop) has a replaceable strike pad for easy maintenance. This bump stop utilizes a nitrogen fill valve which can be used to fully adjust the compression force. When properly applied, M 9100 (Bump Stop) will effectively decelerate the suspension and prevent harsh bottoming on custom off-road applications.
Collapsed Length (in): 9.61
Extended Length (in): 11.47
Collapsed Length (mm): 244.1
Extended Length (mm): 291.3
Stroke/travel Length (in): 1.86
Compression @0.52m/s: Custom
Rebound @0.52m/s: Custom
Lower Mount Type: Special
Upper Mount Type: Special
Mount Type: Special
Internal Design: Monotube
Finish: Nickel Plated
Reservoir: No
Body Design: Smooth Body (Non-Coilover)
Piston Diameter: 46mm
Spring Seat Included: No
Optional Reservoir Clamp: N/A
Shaft Diameter: 1-1/4 in.
Shaft Diameter (mm): 31.8
Valving Type: Firm
